M-Series

Cost Effective Network Video Recorders

Deprecated

All-in-One Recorder: Easiest to Quote, Install, Service

  • 4 or 8 PoE camera ports, no external Ethernet switch required
  • Up to 6TB of video storage for up to 8 IP cameras
  • Simply plug in and record; automatically configures IP cameras for motion-based recording
  • Monitor and control camera power usage in exacqVision client, no separate switch management software required
  • Save maintenance trips by remotely power cycling individual PoE cameras
  • 30 watts max per 4-ports (60 watts max for 8-ports)
  • Supports PoE camera classes 4w, 7w, & 15w
exacqVision M-Series easy install and setup
exacqVision M-Series All-in-One Video Server preinstalled exacqVision Start VMS Software licenses

View Video Anywhere

  • View and manage servers from Windows/Linux/MAC PCs with free client software
  • View live and recorded video in any browser
  • View live and recorded video on iOS or Android mobile devices with free application
  • Includes 4 or 8 exacqVision START licenses (upgradeable to Pro or Enterprise)
  • Auto detects IP cameras for quick, simple setup
  • Continuous motion, time or alarm-based recording configurable per camera
  • Search recorded video with a timeline search or graphical thumbnail search, playback multiple cameras simultaneously
  • Easily control PTZ cameras
  • Export audio, video and pictures to be easily e-mailed or saved
  • View an instant replay of video from any camera with exacqReplay
  • Easily upgradeable to exacqVision Professional or Enterprise VMS

3-Year Warranty and Software Subscription Agreement (SSA)

  • Constantly increase VMS features with regular software updates
  • 3 years of unlimited software updates included
  • 3 years of system warranty
exacqVision M-Series comes with a 3 year warranty
M, up to 4 POE cameras
Desktop PoE recorder with 4 PoE class 2 IP camera ports (30w max), 4TB maximum, 40 Mbps continuous recording rate. 4 exacqVision START IP licenses, server and client, web/mobile software pre-installed with 3 years software upgrades and hardware warranty, HDMI or VGA, Dual GB client network NIC, 3 USBs, 8 Alarm Inputs, 2 Alarm Outputs. Mouse included with on-screen keyboard installed. Uses HiSilicon 3535 CPU, HiSilicon is a subsidiary of Huawei.
Product Name Storage Size
PE04-01T-M 1 TB
PE04-02T-M 2 TB
PE04-04T-M 4 TB
Options for M, up to 4 POE cameras
(Option Name/Description)
M, up to 8 POE cameras
Desktop PoE recorder with 8 PoE class 2 IP camera ports (60w max), 6TB maximum, 40 Mbps continuous recording rate. 8 exacqVision START IP licenses, server and client, web/mobile software pre-installed with 3 years software upgrades and hardware warranty, HDMI or VGA, Dual GB client network NIC, 3 USBs, 8 Alarm Inputs, 2 Alarm Outputs. Mouse included with on-screen keyboard installed. Uses HiSilicon 3535 CPU, HiSilicon is a subsidiary of Huawei.
Product Name Storage Size
PE08-02T-M 2 TB
PE08-02T-M 4 TB
PE08-02T-M 6 TB
Options for M, up to 8 POE cameras
(Option Name/Description)
